YZ20P5 OPERATION MICROSCOPE(OPHTHALMOLOGY)

·Characteristics

· Portable, three-step magnifications

· Spring balance system in the arm ensures the microscope move freely.

· All of the lens are multi-coated, mildewproof and anti-reflection

· For optional objectives and other parts applicable to ENT, DENTISTRY, LAB and SURGERY, please refer to the followings:

· The whole microscope is smart, portable, specially suitable for mobile hospital.

·Specification

Eyepiece Magnification

12.5×

Objective

200mm

Working Distance

190mm

Magnification for Main Microscope

5.3×、8×、12×

Diameter of Field

Φ38mm、Φ25mm、Φ17mm

Adjustable Dioptor

±5D

Adjustable Range for Pupil Distance

50mm～70mm

Illumination Source

12V/100W，Halogen Lamp

Illumination Type

6°+0°Coaxial Illumination

Coaxial Illumination

≥20000lx

Reaching Range of Arm

870mm

Adjustable Vertical Range

700mm～1100mm

Fine Focusing Range

30mm

Voltage

AC220V±10%/ 50Hz±1Hz、AC110V±10%/60Hz±1Hz

Power

120VA

Fuse

AC250 T1.25A 、AC125V T2.5A

Safety Electrical Standard

Conform to Standard IEC 601-1.Class1Type B

Whole Packing Volume

0.2m3

Carton Number

Total Weight

41kg

·Optional Accessory

· 1/2’’or1/4” CCD camera, CCD Adaptor, Beam Splitter and relevant Cables.

·Straight Binocular Tube, Universal Structure( for ENT).

·Five Objectives: f175mm, f250mm, f300mm, f350mm, f400mm(12.5X eyepiece)

·10X Eyepiece.

·Desktop Parts( Holding Bracket, Column).

·Portable Package( including three canvas bags and a buggy) at customer’s option.
