1.World certified
Toward the best in the world
it has certifications from the FDA, CE, and the ISO 9002 as the company that designed the Ref-Keratometer. The MRK-3100P, designed by the newest technology is exported to all of the world effectively measuring the eyes of the world.
2.Latest optic technology
Variable, Precise Ref/Keratometer
The MRK-3100P measures cornea curvatures, the iris, cataracts, Intraoccular lenses (IOL), CLBC, and the base curvature. All the measuring is accomplished with our wide ranged diopter.
3. Convenient to used
Easy to use, convenient to measure
The MRK-3100P is so easy to use; there is almost no need for a user's manual, making it very convenient and comfortable for the operator as well as the customer.
Function:
Key point:
HUVITZ AUTO RER-KERATOMTER MKR-3100P
CLBC Mode
Contact Lens Base Curve Measurement
Refractometry:
Vertex Distance (VD)
0.0, 12.0, 15.0
Sphere (SPH)
-25.00 ~ +22.00D (VD = 12mm) (0.12, 0.25D)
Cylinder (CYL)
0.00 ~ ±10.00D (Increments : 0.12 and 0.25D)
Axis (AX)
1 ~ 180° (Increments : 1°)
Cylinder Form
-, +, ±
Pupil Distance (PD)
10 ~ 85mm
Minimum Pupil Diameter
Ø2.0mm
Keratometery:
Radius of Curvature
5.0 ~ 10.2mm (Increments : 0.01mm)
Corneal Power
33.00 ~ 67.50D (When corneal equivalent refractive index is 1.3375)
(Increments : 0.05/0.12/0.25D)
Corneal Astigmatism
0.00 ~ -15.00D (Increments : 0.05/0.12/0.25D)
Axis
1 ~ 180° (Increments : 1°)
Corneal Diameter
2.0 ~ 14.0mm (Increments : 0.1mm)
Memory of Data
10 measurements for each eye
Other:
Internal Printer
Thermal Line Printer
Power Saving
Automatic switch off (5 min)
Display
5.5 inch (Black & White) CRT
Power Supply
100-240V~, 50/60Hz ,1A
Dimension
300(W) x 500(D) x 430(H)mm / 21Kg
Weight
20kg
Measurement Mode:
K/R Mode
Continuous Keratometry & Refractometry
REF Mode
Refractometry
KER Mode
Keratometry
1.IOL Measuring mode
The MRK-3100P determines the condition of the eyes automatically to detect if there are IOL's or cataracts, and measure them..
2.Beautiful, clear font
The font is easy to read and stands out, no matter what the background color is. The MRK-3100P supports multilingual menus (English, Chinese, and European languages.)
3.Retrllumination Mode
You can see abnormal crystalline lenses, cataracts, corneas, and scratches on the contact lens with
the IR (Infra Red) light that is reflected from the retina. Using this mode, you can determine how
healthy the customer's eyes are.
We can examine the eyes very precisely because the MRK-3100P supports 4 images (2 images from each eye) and the operator can compare all 4 images at once.
The Retrollumination mode is basically for looking at the eyes. In addition, it is possible for the
information to be displayed as Sph, Cyl, Axis, of the eyes.
4.Multiple charts for fogging method
Select a chart from the 3 available charts depending on the customer's preference, allowing for higher reliability.
5.Pupil,Comea,Iris size Measurements
The MRK-3100P can Measure under 14mm by freezing the image.
6. CLBC (base curvature)
Using the contact lens holder, measure the base curvature of contact lense.
