AUTO REF/KERAUTOMETER RMK-200                                               CE

Specifications

Refractometry

Vertex Distance (VD)

0.0,10.0,12.0,13.5,15.0mm

Sphere Power (SPH)

-20.00 ~ +20.00D (at the vertex distance of 12mm)

(Increments selectable between 0.12D and 0.25D)

Cylinder Power (CYL)

0.00 ~ +10.00 D

(Increments selectable between 0.12Dand 0.25D)

Axis (AX)

1 ~ 180° (Increments: 1°)

Cylinder Form

-, +, MIX

Pupil Distance (PD)

10 ~ 85mm

Minimum Pupil Diameter

2.0mm

Keratometry

Radius of Curvature

5.0 ~ 10.2mm (Increments: 0.01mm)

Corneal Power

33.00 ~ 67.50D

(Increments selectable between 0.12D and 0.25D)

Corneal astigmatism

0.00~-15.00D

(Increments selectable between 0.12D and 0.25D)

Axis

1 ~ 180° (Increments: 1°)

Corneal Diameter

2.0 ~ 12.0 mm (Increments: 0.1mm)

Memory of Data

10 measured value for each right and left eye

Internal Printer

Uses thermal line printer

Monitor

5.6-inch color TFT LCD monitor

Environmental requirements:

Operation

Temperature: + 10 to + 40°C

Humidity: 30 to 85% RH

Storage and Transportation

Temperature: - 10 to + 55°C

Humidity: 10 to 95% RH

Power supply

AC220V, 50Hz

Size

280(W) × 475(D) ×475(H)mm

Weight

Approximately 26kg
