YZ20P OPERATION MICROSCOPE( MULTI-SECTION)

·Characteristics

·The whole microscope is smart.

·Three-step magnifications.

·Spring balance system in the arm ensures the microscope move freely.

·All of the lens are multi-coated, mildewproof and anti-reflection

·For optional objectives and other parts applicable to ENT, SURGERY and , gynaecology.

·Specification

Eyepiece Magnification

12.5×/18B

Adjustable Dioptor

±5D

Adjustable range for Pupil Distance

50mm～70mm

Illumination Source

12V/100W，Halogen Lamp

Illumination Type

6°Coaxial Illumination

Coaxial Illumination

≥10000lx

Reaching Range of Arm

860mm

Adjustable Vertical Range

850mm～1100mm

Voltage

AC220V±10%/ 50Hz±1Hz、AC110V±10%/60Hz±1Hz

Power

120VA

Fuse

AC250V T1.25A 、AC125V T2.5A

Electrical Safety Standard

Conform to Standard IEC 601-1.Class1Type B

Whole Packing Volume

0.283m3

Carton Number

Total Weight

35kg

Objective/Working Distance（mm）

Magnification

Diameter of Field（mm）

f200/190

Φ35

10X

Φ22

16X

Φ14

f250/240

4.2X

Φ52

6.7X

Φ34

11X

Φ20

· Optional Accessory

· f300mm Objective
