SOM2000D OPERATION MICROSCOPE(OPHTHALMOLOGY)

Characteristics

· Zoom magnification for main microscope, three-step magnifications for assistant microscope; Fine focusing for assistant microscope keeps the same clearness as main microscope.

· Lens made of imported glass from Germany can reduce the optical aberration.

· All of the lens are multi-coated, mildewproof and anti-reflection

· X/Y movement and focusing can be automatically centered.

· Special motorized inclinations are suitable for special observation angle.

· Special protection device for objective can keep the objective clean.

· Independent electrical box has automatical diagnosis function , which is very convenient for repair if necessary.

·Specification

Eyepiece Magnofication

12.5×/18B

Objective

200mm

Working Distance

170mm

Magnification for Main Microscope

4×-25×

Magnification for Assistant Microscope

6×、10×、16×

Diameter of Field

Φ50mm～Φ9mm

Adjustable Dioptor

±5D

Adjustable range for Pupil Distance

50mm～75mm

Illumination Source

12V/100W ，Halogen Lamp

Illumination Type

6°+0°coaxial illumination and 26°oblique illumination

Coaxial Illumination

≥35000lx

Oblique Illumination

≥30000lx

Reaching Range of Arm

1230mm

Adjustable Vertical Range

880mm~1420mm

Fine Focusing Speed and Range

≤2mm/s，≥50mm

Speed for X/Y and Range

≤2mm/s，50mm×50mm

Voltage

AC220V±10%/50Hz±1Hz、AC110V±10%/60Hz±1Hz

Power

170VA

Fuse

AC250V T3.15A 、AC125V T6.3A

Electrical Safety Standard

Conform to Standard IEC 601-1.Class1Type B

Whole Packing Volume

0.756m3

Carton Number

Total Weight

215kg

Optional Accessory

· Teaching tube, Beam Splitter.

· 1/3’’ CCD camera, CCD Adaptor, Beam Splitter and relevant cables
